Rated load

额定载荷

1T.2T.3T5T.10T 大量程可订

sensitivity

灵敏度

1.0-2.0mv/v

Optional transmit

可加变送输出

0-5V 、0-10V、 4-20MA、RS485/232

Zero Balance

零点平衡

±1% of rated output

Creep after 30 minutes

蠕变

±0.3% of rated output

Nonlinearity

非线性

±0.3% of rated output

Repeatability

重复性

±0.2% of rated output

Temp. effect on output

灵敏度温漂

≤0.02% of applied output/?C

Temp. effect on zero

零点温漂

≤0.02% of applied output/?C

Safe Temp. Range

可用温度范围

-20?C to + 60?C

Temp. Compensated

温度补偿范围

-10?C to + 40?C

Safe Overload

安全载荷

120%

limit load

极限载荷

150%

Input Impedance

输入阻抗

780?ohm ± 20 ohm

Output Impedance

输出阻抗

750 ohm ± 5 ohm

Rated Excitation

推荐激励电压

10V DC/AC

Maximum Excitation

激励电压

15V DC/AC

Frequency response

响应频率

≤20KHZ
