额定载荷Rated load

100N.M-5000N.M

综合精度Comprehensive accuracy

0.5％F·S （线性+滞后+重复性）(linear + delay + repeatability)

灵敏度sensitivity

1.0～1.5mV/V

可配变送输出Can be suppl

0-5V/0-10V/4-20mA、RS485/232

蠕变creep

±0.5％F·S/30min

零点输出Zero output

±1％F·S

零点温度影响emperature Effect On Zero

±0.05％F·S/10℃

输出温度影响Effect of output temperature

±0.05％F·S/10℃

工作温度范围Operating temperature range

-20℃～+65℃

输入阻抗Input impedance

750±30Ω

输出阻抗Output impedance

700±10Ω

绝缘电阻

≥5000MΩ/100VDC

安全过载Safe Load Limit

120％

极限超载Ultimate overload

150％

供桥电压Bridge voltage

建议10VDCSuggest 10VDC

材质Texture of material

40Cr ?/ 17-4
